Hello Kodular developers and extension developers
I would like to discuss a feature that could significantly expand what Extension developers can build in Kodular:
True Visible Extension Components
I am not talking about Dynamic Components.
I mean a real Extension Component that behaves similarly to a native Kodular visible component.
For example:
AdvancedButton.aix
↓
Import Extension into Kodular
↓
AdvancedButton appears in the Palette
↓
Drag AdvancedButton into the Screen
↓
AdvancedButton is visible in the Designer Viewer
↓
Properties can be edited in Designer
↓
Blocks and Events are available
↓
Build APK
↓
A real Android View is created at runtime
For example:
AdvancedButton
├── Text
├── TextColor
├── TextSize
├── BackgroundColor
├── CornerRadius
├── Icon
├── Enabled
└── Click
What I discovered
I found that this is not a completely new idea.
There was already a GSoC 2020 project called Visible Component Extension (VCE) for MIT App Inventor.
The project’s goal was specifically to allow visible components to be created as extensions, so that they could look almost identical to built-in visible components.
The project actually demonstrated a “SimpleLabel” mock.
The implementation showed that an extension could have a JavaScript mock which created a DOM element and reacted to Designer property changes.
For example, the old proof of concept contained the concept:
class MockSimpleLabel extends MockVisibleExtension {
static TYPE = "SimpleLabel";
constructor(editor) {
super(editor, MockSimpleLabel.TYPE);
this.label = document.createElement("p");
this.initComponent(this.label);
}
onPropertyChange(propertyName, newValue) {
switch (propertyName) {
case "Text":
this.label.textContent = newValue;
break;
}
}
static create(editor) {
return new MockSimpleLabel(editor);
}
}
MockComponentRegistry.register(
MockSimpleLabel.TYPE,
MockSimpleLabel.create
);
The original discussion even shows that the “SimpleLabel” mock could be placed in the Designer and its “Text” property changed successfully.
This is documented in the original VCE discussion:
The relevant implementation discussion and example are around the July/August 2020 updates.
A newer and much more interesting attempt
In 2024, a new GSoC project was proposed:
Mock Preview Support for Extensions
The official discussion:
The project explicitly states that:
«Extensions currently cannot have mock previews.»
The goal was to allow extension developers to provide their own mock preview.
The proposed system uses a JavaScript API for creating mocks and also discusses security, external CSS, and network access.
This is extremely close to what I believe Kodular could use.
The actual implementation exists as PR #3200
The most important resource I found is the actual App Inventor source-code PR:
PR #3200 — Add mock preview support for extensions
Opened:
15 July 2024
The PR currently remains open.
It contains approximately:
+714
-134
35 commits
30 files changed
More importantly, this is not just documentation.
The PR contains actual implementation work including:
- “MockVisibleExtension”
- mock script loading
- packaging mock scripts with extensions
- a test mock for visible extensions
- Dedicated Worker support
- Shadow DOM
- mock sanitization
- external CSS support
- initial property handling
- error handling
- extension upgrade handling
- mock script registration
- mock files stored in extension resources
The GitHub PR can be inspected here:
The architecture is very interesting
The proposed architecture separates the Designer representation from the Android runtime component.
Something like:
Extension
│
┌──────────┴──────────┐
│ │
Runtime Mock
│ │
Java / Kotlin JavaScript
│ │
↓ ↓
Android View Designer View
│ │
↓ ↓
APK Kodular Viewer
This makes sense because Kodular Creator runs in the browser, while the actual Extension runs inside the Android application.
XML is NOT the missing part
I initially thought FAST’s XML support might solve this.
For example, we can easily create an Android layout:
This can be used by the runtime Android component.
But the Kodular Designer cannot simply load an Android XML “Button”.
The Designer needs a browser-side representation.
Therefore we need something like:
Runtime:
Java/Kotlin + Android XML
↓
Real Android View
Designer:
Mock JavaScript
↓
Designer Preview
FAST could still be very useful
FAST is already a powerful Extension build system:
It supports many features useful for a future Visible Extension, including modern Java, Kotlin, Maven/Gradle dependencies, AARs, manifest merging, R8, ProGuard, resource handling, etc.
But I don’t think FAST itself is the missing piece.
The missing piece is:
Kodular Creator
↓
Extension Mock Support
↓
Visible Extension
FAST would then be responsible for building/packaging the runtime extension and potentially its mock resources.
What I would like to know from the Kodular developers
Could the implementation from MIT App Inventor PR #3200 be adapted to Kodular Creator?
Specifically:
Does Kodular Creator already have enough of the Mock Component infrastructure to implement this?
Could “MockVisibleExtension” from the App Inventor work be ported to Kodular?
Could a “.aix” contain something like:
AdvancedButton.aix
│
├── Runtime classes
│
├── component metadata
│
├── Android resources
│
└── mock.js
and Kodular Creator automatically load the “mock.js” when the extension is imported?
Could the extension metadata contain something like:
visible = true
mock = “AdvancedButton.mock.js”
?
Could FAST eventually package this mock file automatically?
For example:
src/
├── AdvancedButton.java
└── AdvancedButton.mock.js
and then:
fast build
produces:
AdvancedButton.aix
with both the runtime and mock included?
Security is obviously an important issue
I understand why this feature is not trivial.
A mock is JavaScript running inside the Designer.
An untrusted extension should not be allowed to freely manipulate the Kodular Creator page, access sensitive data, inject scripts, etc.
Interestingly, the 2024 PR already experimented with several approaches, including:
Dedicated Worker
Shadow DOM
Sanitization
DOMPurify
Linkedom
The PR history specifically includes commits for:
add wrapper for DedicatedWorker
add DOMPurify and linkedom
perform sanitization of mock
render the mock inside Shadow DOM
add external CSS support
This makes PR #3200 particularly interesting as a starting point.
What about containers?
A simple component such as:
AdvancedButton
AdvancedLabel
AdvancedImage
AdvancedSlider
should be relatively straightforward.
But it becomes more interesting for:
AdvancedCard
containing:
Label
Button
The old VCE discussion already identified this issue and introduced the concept of “MockContainer” in addition to “MockVisibleComponent”.
See the original discussion:
Example of what I want to achieve
Imagine an extension:
AdvancedButton.aix
After importing it:
Kodular Palette
│
├── User Interface
├── Layout
├── Media
└── Extensions
└── AdvancedButton
Drag it into the Viewer:
┌───────────────────────────┐
│ │
│ Advanced Button │
│ │
└───────────────────────────┘
Change:
Text = “Hello”
and the Designer mock immediately becomes:
┌───────────────────────────┐
│ Hello │
└───────────────────────────┘
Then when the APK is built:
Mock JavaScript
↓
NOT used in the Android APK
Java/Kotlin Runtime
↓
Real Android View
Why this would be valuable
It would allow Extension developers to create completely new UI components without having to rely on Dynamic Components or hacks.
Examples:
AdvancedButton
AdvancedCard
CustomSlider
CustomProgressBar
CustomChart
CustomVideoView
CustomCameraView
CustomMapView
CustomInput
CustomRecyclerView
The extension developer would control both:
Designer representation
and:
Android runtime representation
while Kodular would remain responsible for the overall Designer/Blocks architecture.
Important distinction
This proposal is not:
Dynamic Components
An extension that creates a Button at runtime
A WebView pretending to be a component
A normal non-visible extension controlling an existing Button
It is:
A real Extension Component
Appears in the Palette
Can be dragged into the Designer
Has a Designer mock
Has Properties
Has Blocks/Events
Has a real Android implementation at runtime
Main resources
- VCE — 2020
- Mock Preview Support — 2024
- Actual implementation — PR #3200
- FAST
- Example of the old VCE implementation
Final question
Could the Kodular team/developers investigate whether the work from App Inventor’s Mock Preview Support PR #3200 can be ported or adapted to Kodular?
If someone has already experimented with this, has a fork/branch, or knows which parts of Kodular Creator need to be changed, I would really appreciate any information.
I would also be interested in helping test a proof of concept such as:
AdvancedButton.aix
+
AdvancedButton.mock.js
↓
Kodular Creator
↓
Palette
↓
Designer Viewer
↓
Properties + Blocks
↓
APK
↓
Real Android AdvancedButton
I believe this could open a completely new level of Extension development for Kodular.
